Form Factor:
M-ATX
Chassis:
SPCC :0.5mm
PSU Form Factor
Bottom/ATX
M/B Form Factor:
M-ATX、ITX
Front Panel:
Plastic + Mesh
Top Panel:
Metal
Side Panel:
Left:
Tempered Glass (Tool-free)
Right:
Metal cover
External Drive Bay(s):
5.25”(ODD):
*0
3.5”:
*0
Internal Drive Bay(s):
3.5" (HDD):
*Up to 2
2.5" (SSD):
*Up to 2
2*3.5HDD+1*2.5SSD or 1*3.5HDD+2*2.5SSD
I/O:
Buttons:
*2 (POEWR, RESET or LED MODL)
USB 2.0 Port(s):
*0
USB 3.0 Port(s):
*1
Type C Port(s):
*1(TYPE-C GEN2)
Audio Support:
*1(Combo AUDIO)
Card Reader (Support):
*0
P-Lock：
*0
RGB Controller：
V5.0 ARGB PWM HUB
Controller Max Fans:
*6
RGB Controller max. LED strips：
*6
Remote (IR or RF)：
*RF
Cooling Fan Support:
Front:
3x120mm (Tornado-T12 ARGB)
Top:
3x120mm ,2x140mm (Fan optional)
Rear:
1x120mm (Tornado-T12 ARGB)
Bottom:
*0
M/B Cover：
*2x120mm (Fan optional)
PSU Cover：
*3x120mm (Fan optional)
Water Cooling Support
(Radiator Size):
Front:
*0
Top:
120mm, 140mm,240mm,280mm,360mm
Rear:
120mm
M/B Cover：
*0
Dust Cover:
Dust mesh on the bottom and top
Slots:
*4
Carton & Logo:
GAMEMAX
Dimensions:
Chassis:
(L)458*(W)220*(H)395mm
Full Case (Inc Fascia):
(L)483*(W)220*(H)408mm
Carton:
(L)452*(W)277*(H)551mm
Net Weight(kg):
8.4
Gross Weight(kg):
9.4
