Form Factor: E-ATX
Chassis: SPCC :0.6-0.7mm
PSU Form Factor Bottom/ATX
M/B Form Factor: E-ATX、ATX、M-ATX、ITX
ATX、M-ATX Support BTF
Front Panel: metal Mesh(Tool-free)
Top Panel: metal Mesh(Tool-free)
Side Panel: Left: Tempered Glass(Tool-free)
Right: Metal cover(Tool-free)
External Drive Bay(s): 5.25”(ODD): *0
3.5”: *0
Internal Drive Bay(s): 3.5" (HDD): *2
2.5" (SSD): *3
2*3.5HDD+2*2.5SSD or 1*3.5HDD+3*2.5SSD
I/O: Buttons: *3 (POEWR, RESET, LED MODL)
USB 2.0 Port(s): *0
USB 3.0 Port(s): *2
Type C Port(s): *1(TYPE-C GEN2)
Audio Support: *1(Combo AUDIO)
Card Reader (Support): *0
P-Lock： *0
RGB Controller： *1(V5.0 PWM ARGB HUB)
Controller Max Fans: *6
RGB Controller max. LED strips： *6
Remote (IR or RF)： *1
Cooling Fan Support: Front: 3x140mm( FN14A-S5)
Top: 3x120mm ,2x140mm (Fan optional)
Rear: 1x140mm( FN14A-S5)
Bottom: 0
M/B Cover： 0
PSU Cover：
2x120mm ,2x140mm (Fan optional
Water Cooling Support
(Radiator Size): Front: 120mm, 140mm,240mm,280mm,360mm,420mm
Top: 120mm, 140mm,240mm,280mm,360mm
Rear: 120mm, 140mm
M/B Cover： *0
Dust Cover: Removable iron mesh on top, pull-out dust mesh on the bottom
Slots: *7/5
Carton & Logo: GAMEMAX
Dimensions: Chassis: (L)440*(W)235*(H)480mm
Full Case (Inc Fascia): (L)476*(W)235*(H)500mm
Carton: (L)558*(W)309*(H)565mm
Net Weight(kg): 9.2
Gross Weight(kg): 10.6
VGA Support: up to 425mm(inside the front cover w/o fan)
Vertical Graphics Support YES
CPU Cooler Height: up to 185mm
SPS Length: up to 245mm
Cable Management Depth: 32mm
