Form Factor (Midi, Micro, Mini ITX, Full) Full Tower
Chassis SPCC 0.8mm . Black painting interior
PSU Form Factor Bottom/ATX
M/B Form Factor EATX(280*305)、ATX、M-ATX
Front Panel ABS
Top Panel ABS,Mesh,Cover by EPDM Sound Dampening Material
Side Panel Left Metal ,Cover by EPDM Sound Dampening Material
Right Metal ,Cover by EPDM Sound Dampening Material
External Drive Bay(s) 5.25" (ODD) *3
3.5" *0
Internal Drive Bay(s) 3.5" (HDD) *8
2.5" (SSD) *2
I/O Buttons *2(Power SW,Rest SW)
USB2.0 Port(s) *2
USB3.0 Port(s) *2
USB3.1 Port(s) *0
HD Audio Support *1(COMBO*1+MIC*1)
Type C (GEN2) *1
Fan Speed Controller *2(ON the Top panel)
9905-V2.0 HUB *1
Cooling Fan Support Front 2x120mm(GMX-WFBK,Fan included)
Top 3x120mm ,2x140mm (Fan optional)
Rear 1x120mm (GMX-WFBK,Fan included)
Left Side 0
Bottom 1x120mm (Fan optional)
Water Cooling Support
(Radiator Size) Front 120mm/240mm
Top 120mm/140mm/240mm/280mm/360mm
Rear 120mm
Dust Cover Bottom ,top,Front cover with dust filter
Slots *8
Carton & Logo GAMEMAX
Dimensions Chassis (L)470*(W)210*(H)465mm
Full Case (inc Fascia) (L)512*(W)210*（H)527mm
Carton (L)579*(W)286*（H)597mm
Net Weight (Kg) 9.1kgs
Gross Weight (Kg) 10.8kgs
VGA Card Length 420mm( remove drive cage that GPU longer than 300mm)
CPU Cooler Height 170mm
Cable Management Depth 20mm
