Factory #Diamond CP
SPECIFICATION
Form Factor (Midi, Micro, Mini ITX, Full) Midi ATX Tower
Chassis SPCC : 0.5mm
PSU Form Factor Bottom/ATX
M/B Form Factor ATX、M-ATX、ITX
Front Panel ABS
Top Panel metal cover
Branding Box GameMax standard
Unit 1
Side Panel Left Tempered Glass
Right metal cover
External Drive Bay(s) 5.25" (ODD) *0
3.5" *0
Internal Drive Bay(s) 3.5" (HDD) *2
2.5" (SSD) *2
I/O CONFIG Buttons *2
USB2.0 Port(s) *1
USB3.0 Port(s) USB3.1 GEN1 *1
HD Audio Support *1
Card Reader (Support) *0
P-Lock *0
RGB Controller *1 Build-in Master FAN
Controller max. fans
RGB Controller max. LED strips
Remote (IR or RF) *Top RGB switch
Cooling Fan Support Front 3x120mm,2x140mm(Fan optional)
Top 2x120mm(ARGB Fan Included),2x140mm (Fan optional)
Rear 1x120mm (ARGB Fan Included)
MB Plate 1x 140mm Turbo Fan (Included)
PSU Cover 2x120mm (Fan optional)
Water Cooling Support
(Radiator Size) Front 120mm, 140mm,240mm,280mm
Top 120mm, 240mm
Rear 120mm*1
Dust Cover Bottom and top cover with dust filter
Slots *7
Carton & Logo GAMEMAX
Dimensions Chassis (L)360*(W)210*(H)440mm
Full Case (inc Fascia) (L)421*(W)210*（H)460mm
Carton (L)*(W)*（H)mm
Net Weight (Kg) 4.4kgs
Gross Weight (Kg) 5.3kgs
VGA Card Length up to 340mm
CPU Cooler Height 170mm
Cable Management Depth 22mm
