| Technical Specifications |
| 80PLUS® |
None 80+ |
| Efficiency Level |
>75% |
| Noise Level |
Zero (ECO-ON),<32dBA (at 100% load) |
| Form Factor |
Intel ATX 12 V 2.31 |
| Dimensions |
140 mm (W) x 150 mm (L) x 86 mm (H) |
| Fan Information |
Fan Size |
120 mm |
| Fan Control |
ECO-ON/OFF |
| Fan Bearing |
Fluid Dynamic Bearing |
| Life Expectancy |
50,000 hours at 40 °C, 15 % - 65 % RH |
| Cable Information |
Modularity |
Wired Cabling |
| Cable type |
Black tube shield along with colors CPU and PCIe connecor |
| Electrical Features |
Operating Temperature |
0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
| MTBF @ 25 °C, excl. fan |
100,000 hours |
| AC Input |
AC 115/230V by manual switch |
| Protection |
OPP, OVP, UVP, OCP, OTP, SCP |
| Safety and Environmental |
Safety and EMC |
CB, CCC,CE |
| Environmental Compliance |
RoHS, WEEE, ErP Lot 6 |
